Monocular Video Microscope MZDH0850C

High-Resolution Zoom
Monocular Video Microscope

Magnification    0.75x ~ 0.5x (6.7:1)

FOV(mm)           6X4.5 ~ 1.0X0.7

Illumination         Co-axial, LED 1W/ 3W

Contact

High-Resolution Zoom
Monocular Video Microscope







Zoom Range

0.75X~5.0X
extend total magnification: 0.07X~50X(use auxiliary objectives and kinds of magnification CCD adapters)

Zoom Ratio

6.7:1

F.O.V (mm)

6X4.5~ 1.0X0.7

Working Distance(WD)

82mm(1X Objective)

Holder Size

Φ45mm

Illumination

Adjustable high brightness(1W/3W), long life LED Coaxial illumination, ring illuminator

Mount

Standard C-Mount

MZDH0850 Series Diagram
