ST70 STEREO MICROSCOPE

SKU: ST7024-B1
  • Guarantee: 1 Year
  • Made in: China

Contact

Category:

ST70 Series Stereo Microscope is fully coated optical system with super high resolution. It offers sharp clear images with extremely great flatness and contrast. With the new ergonomics design and super large field of view, you can use this microscope for long time without fatigue. It is widely used in electronic industry, educational demonstration and agricultural research for micro-object observation, inspection and measurement.

Eyepiece

Objective 1X

Objective 2X

Objective 3X

Objective 4X

Working Distance 100mm

Mag.

F.O.V

Mag.

F.O.V

Mag.

F.O.V

Mag.

F.O.V

10X/23mm

10X

20.0mm

20X

10.0mm

30X

7.5mm

40X

5.0mm

15X/16mm

15X

16.0mm

30X

8.0mm

45X

5.0mm

60X

3.3mm

20X/12mm

20X

12.0mm

40X

6.0mm

60X

3.3mm

80X

2.5mm

25X/9mm

25X

9.0mm

50X

4.5mm

75X

3.0mm

100X

2.3mm

30X/8mm

30X

8.0mm

60X

4.0mm

90X

2.7mm

120X

2.0mm

Magnification

  20X-40X, 10X-120X with optional eyepieces and objectives

Eyepiece

  WF10X/23mm high-eyepoint, super wide-field; Convenient for observers wearing glasses

Optional Eyepiece

  WF10X/23mm, WF15X/16mm, WF20X/12mm, WF25X/9mm, WF30X/8mm

Main Body

  Binocular head, 45° inclined, 360° rotatable, can be locked in any position desired
  Interpupillary Distance adjustment:54-75mm; Diopter adjustment:±5 diopters

Objective

  2X/4X, 1X/3X, 1X/2X

Focusing Mount

  A1 focusing mount with vertical working distance 50mm

Stand

  B1 pole stand, for more options, please refer to “ACCESSORIES-MICROSCOPE STAND”

Illumination

  Fluorescent lamp, LED ring light, for more option, please refer to “ACCESSORIES-ILLUMINATOR”
